Fodenn Factory direct supplies Windows11 Home/Win11 pro/Win11 IOT / Ubuntu Operating System Micro PCs,Powered by Intel Alder Lake N-Series Office NUC Computer Gaming Desktop Mini computer with 1x DDR4,4x USB3.2,2x HDMI,1x LAN Support OEM
Platform :
Mobile / DesktopSize Type :
116*102.6*38mm Tiny Mini PCsCPU :
Intel Alder Lake-N Series N95 N100 N300 CPU,1.7GHz,Max 3.40GHzRAM (Memory) :
1x DDR4 SO-DIMM,8GB,16GB, Max 32GBLAN :
1x RJ45 Gigabit EthernetUSB :
4x USB3.2Display :
2x HDMIOS Support :
Win11 Home/Win11 pro/Win11 IOT/ UbuntuShell Material :
Full plasticItem No :
Mini PC -F10Brand :
Fodenn (support OEM ODM)Processor and Performance:The F10 Mini PC is powered by the latest Intel Alder Lake-N series processors, including the N95, N100, and N300 options. With speeds reaching up to 1.7GHz and a turbo boost maximum speed of 3.4GHz, these processors deliver impressive performance while maintaining a low power consumption of just 15W.
Memory and Storage:This micro computer comes with a single SO-DIMM slot supporting DDR4 memory with speeds up to 3200 MT/s. Users can choose from 4GB, 8GB, 16GB, or 32GB memory capacities to suit their needs. For storage, the Mini PC F10 supports M.2 2280 NVMe/NGFF SSDs, offering up to 2TB of storage capacity, or a 2.5-inch SATA interface HDD/SSD, also with a maximum capacity of 2TB.
BIOS Features:The F10's BIOS supports real-time clock, scheduled power-on, and auto-power-on after electricity is applied. It also supports Wake-on-LAN and TPM 2.0, providing advanced security features for data protection and system integrity.
Connectivity:Despite its small form factor pc, the F10 is equipped with a single RJ45 Ethernet LAN port for wired connectivity, 4x USB 3.2 ports for high-speed data transfer, and 2x HDMI ports for audio and video output, making it a versatile choice for various display setups.
Wireless Capabilities:The F10 Mini PC supports M.2 WiFi 5 or WiFi 6, ensuring fast and reliable wireless connectivity for internet access and data transfer.
Operating Systems:The F10 is compatible with a range of operating systems, including Windows 11 Home, Windows 11 Pro, Windows 11 IoT, and Ubuntu, providing users with the flexibility to choose the OS that best suits their needs.
Power and Environmental Specifications:The F10 supports a 5.5/2.1mm DC power input and is designed to operate in temperatures ranging from 0℃ to 40℃, with a storage temperature range of -20℃ to +60℃. The power adapter supports input voltages from 100-240V at 50/60Hz, outputting 12V/2.5A. The F10 also supports VESA mounting for space-saving installation options.
Design and Applications:With dimensions of just 116*102.6*38mm and CE certification, the Mini PC F10 is compact, lightweight, and easy to carry. Its low power consumption and energy-saving design make it an environmentally friendly choice. The F10 is suitable for a wide range of applications, including gaming, mobile office work,entertainment and etc.
| Mini PC F10 Low Power Potable Mini Computer | |||
| Appearance | |||
| Type | Details | Configuration | Option |
| Physical parameters | Product Name | MINI PC | |
| Features | Extremely small MINI PC | ||
| Dimension | 116*102.6*38mm | ||
| Shell Material | Full plastic | ||
| Weight | |||
| Hardware Configuration | |||
| CPU | Type | Intel Alder Lake-N N95 | Optional |
| Speed | 1.7GHz | ||
| Maximum speed after turbo frequency | 3.40 GHz | ||
| Power consumption | 15W | ||
| Memory | Type | 1*DDR4 SO-DIMM | |
| Capacity | 8GB ，16GB Max 32GB | 16G | |
| Storage | SSD | M.2 2280 NVME/ NGFF，Max 2TB | 512G |
| 2.5 inch HDD/SSD | Optional, 2.5-inch SATA interface, Max 2TB | Optional | |
| RTC | BIOS Support | Real-time clock, scheduled boot | |
| Automatically Boot | BIOS Support | Support automatic boot function after power on | |
| Wake on LAN | BIOS Support | Support network wake-up | |
| TPM | CPU integrated TPM | Support TPM 2.0 | |
| Dual screen output | Video output | Support 2*HDMI under the system | |
| Internet Connection | |||
| WIFI | Type | M.2 wifi 5 or wifi 6 | Optional |
| Protocol | PCIE | ||
| Bluetooth | Type | Bluetooth 4.2/5.2 | |
| Protocol | USB2.0 | ||
| Ethernet | LAN1 | 10M/100M/1000M adaptive | |
| I/O Port | |||
| USB | USB3.0 | USB3.2 Type-A*4 | |
| HDMI | Audio and Video Output | HDMI 2.1 Type A x2 | |
| RJ45 | Gigabit Ethernet | RJ45 x1 | |
| POWER Button | Power Button | x1 | |
| DC IN | Power Input | 5.5/2.1mm DC Jack x1 | |
| Audio-in/out | Audio Input/output | 3.5mm Phone Jack x1 (2-in-1 port) | |
| Antenna1 | FPC Antenna | WiFi 2.4+BT x1 | |
| Antenna2 | FPC Antenna | WIFI 5.0 | |
| Software Configuration | |||
| Operating system | OS Version | Win11 Home/Win11 pro/Win11 IOT/ Ubuntu | |
| Applicable Environment | |||
| Environment | Operating Temperature | 0~40℃ | |
| Storage Temperature | -20~60℃ | ||
| Humidity | 90% @ 40 °C (no condensation) | ||
| Accessories | |||
| Power Adapter | Wall-mounted/Desktop | Input 100~240V 50/60Hz, Output 12V/2.5A | |
| VESA Wall mount | Support | ||
The Fodenn F10 Mini PC is a powerhouse of versatility, designed to excel in a variety of applications where space is at a premium, and performance is non-negotiable. Its compact form factor, coupled with the latest Intel Alder Lake-N series processors, makes it an ideal choice for scenarios ranging from home entertainment to industrial applications.
Home Entertainment:
Transform your living space into a dynamic home entertainment hub with the F10. Its ability to stream videos, music, and other content seamlessly makes it a perfect media center. Connect it to your TV or monitor to enjoy an immersive, clutter-free entertainment experience. For gamers, the F10's processing power ensures that popular gaming titles run smoothly, providing a delightful gaming experience without the bulk.
Small Businesses:
Small businesses can benefit immensely from the F10's compact size and low power consumption. As a point-of-sale system, digital signage display, or a general-purpose desktop computer, the F10 meets the diverse needs of small enterprises. Its reliability and efficiency make it an indispensable tool for day-to-day operations in a small business environment.
Education:
Educational institutions can leverage the F10 to support coding applications and various programming languages, making it an excellent device for teaching programming. Its compact design and versatility are ideal for creating interactive learning environments in classrooms or computer labs, facilitating a more engaging and hands-on learning experience.
Industrial and Embedded Systems:
The F10's robust performance and compact nature make it well-suited for industrial and embedded systems. It serves as a reliable control unit for machinery, enabling sensor monitoring and performing specialized tasks required in industrial settings. Its small size also makes it perfect for deployment in kiosks and other self-service devices, where space is limited.
Personal Computing:
For personal computing needs, the F10 offers an excellent solution. It handles essential tasks like web browsing, email management, and document editing with ease, providing an efficient and compact computing experience. Its low-power design makes it an environmentally friendly choice for individuals who do not require high-end performance or gaming capabilities.
The Fodenn F10 Mini PC is a versatile device that finds application in a broad spectrum of scenarios, including home entertainment, small businesses, education, industrial and embedded systems, and personal computing. At Fodenn, we understand the diverse needs of our customers and are committed to providing Mini PCs tailored to meet those needs.
